Motoma Inverter
Axpert VM II Premium 3K
Main Features:
- Now With Voltronic Power
- Pure sine wave solar inverter
- Reserved communication port for BMS
- Wide PV input range Battery independent design
- Maximum charging current 100A
- Battery equalization function to optimize battery performance and extend lifecycle
- Built-in anti-dust kit
- 2 years warranty
Documents
Description
The Motoma 3 KW Solar Inverter is a high-performance, reliable solution for powering your energy needs, designed to deliver maximum efficiency and durability. Built with cutting-edge features, it ensures seamless energy management for residential and commercial applications.
Inverter Data Sheet
| MODEL | Axpert VM II Premium 3K |
| Rated Power | 3000VA/3000W |
| INPUT | |
| Voltage | 230 VAC |
| Selectable Voltage Range | 170-280 VAC (For Personal Computers); 90-280 VAC (For Home Appliances) |
| Frequency Range | 50 Hz/60 Hz (Auto sensing) |
| OUTPUT | |
| AC Voltage Regulation (Batt. Mode) | 230VAC ± 5% |
| Surge Power | 6000VA |
| Efficiency (Peak) | 93% |
| Transfer Time | 10 ms (For Personal Computers) ; 20 ms (For Home Appliances) |
| Waveform | Pure sine wave |
| BATTERY | |
| Battery Voltage | 24 VDC |
| Floating Charge Voltage | 27 VDC |
| Overcharge Protection | 32 VDC |
| SOLAR CHARGER & AC CHARGER | |
| Solar Charger Type | MPPT |
| Maximum PV Array Open Circuit Voltage | 450 VDC |
| Maximum PV Array Power | 3000W |
| MPP Range @ Operating Voltage | 30~400 VDC (30~60VDC with battery connected) 60 – 400 VDC |
| Maximum Solar Charge Current | 100 A |
| Maximum AC Charge Current | 80 A |
| Maximum Charge Current | 100 A |
| PHYSICAL | |
| Dimension, D x W x H (mm) | 110 x 288 x 390 |
| Net Weight (kgs) | 7.2 |
| Communication Interface | RS232/RS485 For Lithium Battery BMS communication |
| ENVIRONMENT | |
| Humidity | 5% to 95% Relative Humidity (Non-condensing) |
| Operating Temperature | -10°C to 50°C |
| Storage Temperature | -15°C to 60°C |
